Drop Cable LAN/FTTH Mechanical Fiber Mechanical Splice/fast connectors fiber optic
Base specification
Product details
Product Specification
| Place of Origin | Dongguan, China (Mainland) | Packaging Details | Package Type: 10pcs/small bag carton packaging Fiber Cold Sub Optic Cold Connectors |
| Model Number | Fiber cold connector | Supply Ability | 2000 Piece/Pieces per Week |
| Certification | ISO90012015, SGS | Name | Optic fiber fast connector |
| Brand Name | Qingying or QY | Payment Terms | L/C, T/T or more |
| Color: | Black | Price | US $0.8-1 / Piece |
| Delivery Time | Shipped in 5 days after payment | weight: | 3g |
| Minimum Order Quantity | 20 Piece/Pieces | Adapt cable | Drop cable |
Product Description
Drop Cable LAN / FTTH Mechanical Fiber Mechanical Splice / fast connectors fiber optic
Description:
Wholesale fiber optic cold joints Splice (of telecommunications standards, testing all over) .
This is a rapid Splice excellent performance, able to weld the technical performance indicators:
1, insert the average attenuation is less than 0.20db; typical values: 0.1db
2, joints tensile strength greater than 400 g, the working temperature: -40 to 80 temperature
3, fibers types: single mode 9/125, multimode 62.5/125, 50/125.
4,Can be reused, short connecting time, Simple and easy to use.
5,Suitable for single-mode or multimode fiber
Mainly used in FTTH poor field conditions of the construction site, on-site fiber testing, laboratory activities fiber coupling links and so on.
1. Features:
Easily and rapidly operate with firm and reliable performance.
High reliability and low costs.
Good repeatability.
Excellent heat endurance.
Lower insert loss and higher return loss.
Long service time.
2. Application:
Apply to various single mode and multi-mode connection (diameter:0.25 to 0.25;0.9 to 0.9; 0.25 to 0.9). It can be used for LAN, FTTH, damaged lines repair and optical communication system.
3. Technical Parameters:
| Item | Parameters |
| Average insertion loss | ≤0.2dB |
| Return loss | ≥50dB |
| Insertion times | 50times |
| Operating time | 30s |
| Tensile strength | ≥500g |
4. Environmental Parameters:
| Item | Parameters |
| IL change under circulatory testing as temperature change | <0.05dB@-40℃~+80℃ |
| Operating temperature | -40℃~+80℃ |
| IL change under vibration | ≤0.05 dB |
| IL change when immersing it in the water | ≤0.1 dB |
| Service life | ≥35years |
